Product informations

Summary about the
IVS H Column Loudspeaker

The most common model of the IVS product line with narrow vertical and hypercardiod horizontal coverage, available in length from 1 to 8 meters. The IVS column speakers were applied with excellent result in railway stations, house of worships, swimming pools, sport facilities, auditoriums. With our systems we achived good sound quality and speech intelligibility in many cases, even in these highly reverberant environments.

Pattern Bg

Specification:

  • Nominal length:

    2 m
  • Frequency range:

    150 Hz – 16 kHz
  • Vertical dispersion:

    @250 Hz: 2x25° @500 Hz: 2x12° @1000Hz: 2x6°
  • Horizontal dispersion:

    @250 Hz: 2x90° @500 Hz: 2x80° @1000Hz: 2x70°
  • Directivity factor:

    @250 Hz: Q=7,6 @500 Hz: Q=15,8 @1000Hz: Q=37,2
  • Max. sound pressure:

    129,2 dB
  • Nominal power:

    720 W
  • Musical power:

    1440 W
